geo-FENNEL Multi-Digit Pro Plus Digital Angle Measurers
Product Overview
Electronic angle measurer, electronic slope measurer and laser spirit level. Easy and accurate. For measuring angles, inclinations, sloped and plane surfaces.
Features
- Displays angle and inclination simultaneously
- Different signal tones when approaching 0° / 90° and continuous tone at 0° / 90°
- Inclination direction indication
- Zero position re-set at any position
- Automatic digit inversion for overhead measurements
- Visible laser beam to extend working range
- HOLD function to freeze measurement
- Illuminated display
- Magnetic base
- 1/4“ thread for camera tripod
- 180° lock to extend the unit to 1 m length
- Arm can be locked in any position
Includes
- Padded bag
- Batteries
Specifications
| Working range inclination | 4 x 90° |
| Resolution | 0.1° / 0.1% |
| Accuracy inclination | 0° and 90° = ± 0.1° |
| 1° - 89° = ± 0.2° | |
| Measuring units | °, %, mm/m, in/ft |
| Working range angle | 0° – 180° |
| Resolution | 0.1° / 0.1% |
| Accuracy angle | ± 0.1° |
| Working range laser | 20 m |
| Accuracy laser | ± 0.5 mm / 1 m |
| Wave length / laser class | 650 nm / 2 |
| Power supply | 3 x AA Alkaline |
| Operating time | w/o laser 48 h |
| with laser 20 h | |
| Temperature range | -10 °C bis 45 °C |
| Weight (incl. Batteries) | 1.3 kg |
| Size | 520 x 63 x 30 mm |
| Unfolded length | 1000 mm |
